How to check the battery’s capasity

The gradual degradation of battery takes place with every charge-discharge of the accumulator during the mobile phone’s exploitation. This process is inevitable and it is not connected with the model of the smartphone, its cost or functionality. The lithium-ion and lithium-polymer batteries are used in modern smartphones. Lithium batteries lose about 50% of their capability after 500 charges and discharges. It is commonly said that it’s normal. During 2-3 years of constant work they are running out of their resources. And there is a logical question: for how long the battery’s capacity will work and when should we prepare for changing it?

What is the battery’s capasity

The battery’s capacity is an ability to save and to return energy of electrical DC power. The unit of measurement of battery’s capacity is ampere-hours or watt-hours. Speaking easy, the battery’s capacity of the smartphone shows for how long the accumulator could supply energy. For example, 750 mAh shows that the battery can give electrical power of 1 mA while 750 hours.

The battery’s capacity is counted as a mathematical product of discharge time on an amount of electrical DC power: C=T*I.

Different chemical processes take place in the phone’s battery which lead to its degradation. For example, the volume and compound of electrolyte change and the overall state of electrode’s material as well. As a result, the capacity gradually lowers and afterwards we can change the battery.

How to check the battery’s state

The first advice is to observe your smartphone. If your lithium battery has some problems, you will see them: swellings, lots of corrosion with white and light green spots on it. If you observed these problems, you should stop using your mobile phone, because it could lead to some bad consequences. Electrolyte could seep out from the battery, so, the microcircuit would be shortened. It would be a lot more problems with your smartphone. By the way, you may not notice the swelling on your battery from the very beginning. It goes from the little one to the big one. However, if you want, you can read some information what to do when you have a swelling on your battery, it would be useful in such situation.

Also, it might seem strange if your battery works less than before. For instance, if it saved energy for 3 days before, but now it saves only during a day (at the same exploitation intensity), this is an emergency sign for your telephone’s state.

Moreover, after using all of the battery’s resources it can show to the telephone’s owner strange indicators of charge, for example, it can show 25% and after a short telephone call it can show 0% and go off. For not having such situation, the owners of smartphones should take a power bank whenever they go.

Apps with information about your battery

You can find the exact information you need not only with the telephone’s observation, but also with some special apps and commands for OS. Let’s observe some of them.

iOS

For iPhone users it can be advised to use an utility iBackupBot. It is better to use an app because it is a very comprehensive process to find the information from your settings. For using iBackupBot, you should install it on your PC and connect it with your iPhone, and to start a program after.

Then you need to choose your device among others and click on “More information” button. This program will show you all the information about charge-discharge cycles and the capacitance. If this amount is less than 50%, this way, the accumulator should be changed. iBackupBot can be used for PC and Mac.

For finding the information about your accumulator on an Android platform, you should send a request *#*#4636#*#* and click the button “information about this accumulator”. After that you’ll see everything you need on the display screen.

“Battery” program
This app can be downloaded from GooglePlay. It shows the current state of the accumulator, its voltage and temperature, etc.

How to check the accumulator’s capasity?

For checking this precise information you can use advanced charging devices. If you have a multifunctional charger like iMAX B6, you can use it for revealing the information you need. For making this action you need to wait until the full discharge of the smartphone (when it’s off).

Measuring capacity with iMAX B6

Then connect it to iMAX B6 or to another charger. After that set the accumulator’s type, the charging regime and start the process. The device counts the capacity depending on the time and the volume of electrical DC power.

This process can be done in reverse: firstly, make a full charge and then discharge the smartphone with the same charging device, measuring time and electrical DC power. In the end you’ll see a result – a real capacity of external accumulators for smartphones and laptops.

Stars: 1Stars: 2Stars: 3Stars: 4Stars: 5 (1 votes, average: 5.00 of 5)
Loading…

Myths about the batteries that everybody should forget

Many people think that the limitations which are connected with the batteries on the nickel basis remain still even for lithium-ion and lithium polymer technologies. But, everything which was actual about it in 90s is now a thing of the past. Here are some common myths about the mobile phone’s batteries.

Myth №1: After completing the full charge on your mobile phone you should immediately disconnect it from the supply.

This statement is not about how things are going. All the smartphones, laptop computers and other electronic devices stop the process after getting the full charge. So, the truth is that if your telephone stays all night on the charging station, this won’t affect the future life of your battery. All in all, it is not harmful for the phone’s battery. However, the laptops’ developers recommend to fully discharge your “little computer” approximately 1 time per 2 months.

Myth №2: You should always let your battery to discharge fully

Modern accumulators are not about the full discharge, really. Even if your mobile phone shows you 0% of charge it saves nearly 10% of total energy resources. That’s why when you push the button of charging, the next notification will come to you not so soon. Your misconception will only shorten the life of your battery. Discharging your smartphone till 0% every day slowly reduces the battery’s capacity. And, conversely if you want to make the battery’s life longer, stop letting your phone or laptop discharging all day long.

Myth №3: It is necessary to have a full charge of the battery before the 1st usage.

Actually, it will be okay if you would skip this step. But why some distributers remind us of that? The thing is that the full charge before the 1st usage is the starting point in the process of calibration. To tell the truth, almost every modern battery is «self-calibrated», so you need not to realize this step.

Myth №4: You need to keep the batteries in the fridge.

All in all, keeping the batteries in the fridge or in the freezer is not only bad, but it is also dangerous. Every extreme temperature: no matter if it is high or low – it would do harm for the battery, because the battery consists of different chemicals that save energy. So, this might be very dangerous because of the connection between temperatures and chemical reactions. This is applicable for Energizer batteries too. In order to maximize the expiration date, the manufacturers offer to keep such batteries in the normal conditions with the room temperature (from 20 to 25 C). And also the humidity level should be moderate (from 35 to 65%). So, using such conditions, the alkaline cylindrical elements save their ability to work for 10 years. The service time of lithium batteries is from 10 to 15 years.

Stars: 1Stars: 2Stars: 3Stars: 4Stars: 5 (1 votes, average: 5.00 of 5)
Loading…

Top-5 portable mobile power bank batteries of 2017

Modern smartphones and tablets are now equipped with such power, which even computers didn’t have yesterday. The computing power does not stand still, however, the situation with batteries is much worse. In 2017, the phones are equipped with batteries that offer only 1-2 days of autonomy in a mixed mode of use. And with a heavy load, the smartphone may not hold out until evening.

External batteries (Power Banks) come to the rescue. These are compact devices that have been created with a single purpose – to accumulate energy and charge external devices. On Galagram we’ve made a top 5 best external batteries for your gadgets, which you could buy in 2017.

1. The most capacious battery — 20,000 mAh Xiaomi Power Bank 2

Main features

  • a large capacity of 20,000 mAh
  • output: 5V/2.4A
  • manufacturer: Xiaomi

This battery comes in a plastic casing and with a relatively compact size offers a huge capacity of about 20,000 mAh. It has the high-quality lithium polymer batteries installed inside, and the output voltage is 5V / 2.4A. With the help of 20,000 mAh Xiaomi Power Bank 2 you can even charge high-voltage devices such as Apple iPad and even Mi Book Air and MacBook laptops.

In addition, it supports fast charging in both directions: charging itself and charging connected devices. The size of this monster is 135.5 × 67.6 × 23.9 mm, and the weight is 330.5 grams. Not very small, but it can charge your smartphone with a 3000 mAh battery more than 4 times. With this kind of gadget, you don’t have to worry about autonomy at all. The average cost of this powerbank is $39.

2. Solar-powered powerbank for travelling

Main features

  • solar charging
  • built-in LED flashlight
  • compas
  • good capacity: 12,000 mAh

A huge advantage of this solution is the ability to charge the external battery itself not only by plugging it into a socket, but also using solar energy. Those who travel a lot will love this solar-powered Power Bank, because it’s convenient for usage on the road and during long distance trips.

This 12.000 mAh battery, with dimensions of 139 × 75 × 20 mm, weight of 230 grams and in a moisture protected case, is in our top 5. Of course, on its front face there is a solar battery, and on the end face there are three ports: micro USB for charging the bank itself and two regular USB for charging external devices. Approximate price in China – $15.

3. Mi Power Bank Pro — external battery with quick charge option

Main features

  • Qualcomm Quick Charge 3.0
  • capacity: 10,000 mAh
  • charging via USB Type-C port

If the charging speed is critical for you and you can not wait long till all your devices around the house get charged, then pay attention to the Mi Power Bank Pro battery. Its nominal capacity is 10,000 mAh, and Qualcomm Quick Charge 3.0 is responsible for fast charging of your gadgets.

This gadget is charged via USB Type-C cable and has four LED indicators on the case to display the charge status. Mi Power Bank Pro goes in two colors: graphite black and female pink. You can buy this battery for about $30.

4. Power Bank with a flashlight in a protected case

Main features

  • moisture and dust protected case
  • two powerful flashlights
  • capacity: 10,000 mAh
  • carbine for fastening on a backpack

If you like wildlife, but can’t imagine your vacation without a smartphone – it’s time to get an external battery with a flashlight and additional case protection. This solution has a capacity of 10,000 mAh, several colors to choose from and advanced features like a solar battery and a built-in dual flashlight.

As you may have already guessed, the flashlights use the energy of the power bank. By the way, its body is protected from moisture, so you don’t have to worry if you spill coffee on it, or drop it into the lake while fishing. The output voltage is 5V / 2A, and the battery weight is 290 grams. You can buy the device on Aliexpress for around $15-16.

5. Power Bank with a speaker for music lovers

Main features

  • music playback from a microSD card and smartphone
  • can charge gadgets
  • AUX out

A true music lover always has music with him. Especially for audio fans, Chinese manufacturers have made a Power Bank with a built-in speaker which can play music. The model is called Piple S5 and it can not only playing music from a microSD card, but also charge your gadget.

There are several useful features on the body of this speaker-PowerBank: 3.5 mm audio output, a port for charging gadgets, AUX output and music control keys. You can play music even from your smartphone via Bluetooth 4.0. The price is $39.

Stars: 1Stars: 2Stars: 3Stars: 4Stars: 5 (1 votes, average: 5.00 of 5)
Loading…

Surface Pro 4 battery life

Almost every change in Surface Pro 4 seems to fine-tune the existing tablet. Its universal design is made almost flawlessly.

With a reduction in thickness, an increase in screen size within the previous tablet sizes, dramatically improved Type Cover (keyboard case), the head of the Microsoft Devices group, Panos Panay and his team, took note of each feedback item. The result – the most sophisticated product of Microsoft to this day. It certainly has a lot of virtues, but let’s talk about it’s battery.

What immediately alerted that the Surface Pro 4 battery capacity is slightly lower than the Surface Pro 3 ones, which was explained by the smaller thickness of the first one. But the 4th version has a larger screen, increased resolution and higher brightness. Everything goes towards the fact that autonomy should be significantly reduced. But everything turned out to be quite different. My tablet worked up to 18 hours a day, if I performed the simplest tasks on the Internet. If I watched videos, it was enough for 5 hours of continuous watching. At the same time, I had all communication services and background programs up and running.

One day I decided to turn on the Power Saver mode, set the brightness of the screen to minimum and the tablet worked for 25 hours. But truly, I was only messaging on Facebook and read news on the Internet. One day the tablet was just left on the table for 24 hours and the level of charge fell only half.

In other words, the Surface Pro 4 battery though does not offer record capacity, but on the other side perfectly copes with its tasks. Especially if you compare it with the iPad Air 2, which works for me no more than 5 hours.

Microsoft Surface Pro (2017) battery life

More than 18 months after releasing the Surface Pro 4, the company introduced the fifth generation of Microsoft Surface Pro (2017), the company did not name it Pro 5, the numeration is no longer exists. The new Surface Pro is in some ways an update to Surface Pro 4 and does not have any latest innovations.

Microsoft uses a 45-watt battery in Surface Pro (2017), which is an improvement over the 38-watt battery in Surface Pro 4. The laptop also has a more efficient Intel Core processor on board. In total, the new model offers extended battery life.

Test results:

Peacekeeper test – 5 hours 21 minutes;

Viewing test – 5 hours 37 minutes;

Looped video test – 10 hours 16 minutes.

Generally, the battery of this device has an extended lifetime compared to the previous version – Surface Pro 4.

Stars: 1Stars: 2Stars: 3Stars: 4Stars: 5 (No votes yet)
Loading…

Nintendo switch battery life

The date of the Nintendo Switch’s release was at the 3d of March, 2017.

During the demonstration of Nintendo Switch, the representatives of this company gave a speech about special features of this console and showed different games. However, a few words about the battery were said. The only thing that was mentioned about it, was the fact that the charge’s capacity would be enough only for 2,5-6 hours of playing depending on the project. For example, The Legend of Zelda: Breath of the Wild will take charging resources very quickly, this way, you will always be charging your device without stopping the game. Moreover, you can play this game only for three hours at best while not charging the console.



The battery characteristics

All in all, “Switch” has the biggest battery among other consoles. It is almost twice bigger than the PS Vista’s battery and almost thrice bigger than NEW 3DS.

A little bit more details:

The charge’s capacity is 4310 mAh. The full charging process is about 3 hours. It has a quick charge. Nintendo couldn’t inbuilt a big battery because «Switch» has an active cooling system (another way, there wouldn’t be much space for the cooler and radiator).

The battery will charge 90 minutes till the destination of 80%. Another 20% it will achieve at the same time due to some features of modern batteries.

Nowadays, Nintendo Switch has the biggest charge capacity of all of the accumulators among the so-called «playing » devices. Here is the data to compare:

Nintendo 3DS – 1300 mAh

Nintendo New 3DS – 1400 mAh

Nintendo 3DS XL – 1750 mAh

PS Vista – 2200 mAh

Some users consider the time of an autonomous work of 3-6 hours to be insufficient. However, the other users think that these parameters are balanced, because it was demanded to inbuilt another technical stuff, including the active cooling system.

Changing the battery

As it is known, a standard lithium-ion accumulator loses approximately 70% of its power after some years of usage. This fact will not please Nintendo Switch’s owners who like to play not only on TV screen and at home, but also who like to enjoy the portable mode.

If it is taken into account that, due to the developers’ version, the charge’s capacity would last nearly for three hours without the connection to the doc-station, as the accumulator would be slowly dying, that time (of 3 hours) would be dramatically shortening. What should people do in this case? Right, they should change the battery! But, the problem is that Nintendo Switch’s users will be without the opportunity to change the accumulator by their own. On the other hand, Nintendo intends to offer such service through the support office and to make it commercial.

Stars: 1Stars: 2Stars: 3Stars: 4Stars: 5 (1 votes, average: 5.00 of 5)
Loading…

Have the company really improved the duration of autonomous work of their electronic devices?

One of the main innovations in Galaxy S7 and S7 Edge is their batteries which capacity is more on 18% and 40% respectively in comparison with their predecessors. The last year’s devices were highly promoted by all the points except the battery’s work. Let’s see, whether Samsung could solve this problem this year.

Every test was made thrice and the result was the average rate of these tests. In these tests “the youngest” model took part – Exynos (model number SM-G930F) and also its variant on the base of Snapdragon (model number SM-G930V) of Verizon Wireless. The last one is distributed with pre-installed apps of its operator which can slightly cause the waste of charge. Every device was tested with the identical brightness of the display and in the same conditions.

Wi-Fi

Each smartphone was fully charged and discharged till 0% while testing. After that, they were charged at 2-10% in order to see the registered time of gadget’s functioning.
Exynos Galaxy S7 was a little bit better in this competition and its average time was 6 hours 48 minutes, the Snapdragon version was working 6 hours 30 minutes. It is an interesting fact that the nearest result showed Nexus 6P. Surprisingly, Galaxy Note 5 was a lot better than the new flagman and showed the result of 9 hours 32 minutes.

Video playback

All the devices played the same video again and again till they were fully discharged. Each gadget was in a flight mode for preventing the attempts to synchronize or connect with something.

Both variants of the devices passed this test at their best. The Snapdragon version beat the Galaxy Note 5 and Nexus 6P with the result of 11 hours 52 minutes. The Exynos S7 had really the best result of 15 hours and 11 minutes.

Stand by time

The last was the verification while working in a standby mode. Each smartphone was fully charged and the Wi-Fi was functioning with the standard set of apps and notifications (11 of all of them). Exactly after 24 hours of work the last percentage of charge was measured which was used in calculation the potential time of autonomous work.

Galaxy Note 5 showed the worst result of all. This might have been connected with the absence of Doze Mode function in the Lollipop version of the operating system. Each modification of Galaxy S7 exceeded the result of Nexus 6 model despite of the fact that this gadget has a more powerful battery of 3400 mAh.

The Snapdragon version might have worked 9 days 10 hours and the Exynos model – 10 days 2 hours.

Note

Such tests do not reveal the conditions of everyday usage which is characterized with constant switching between different wires and working of the great diversity of apps which cause a kind of “recent” discharging of the device.
With the active usage of smartphone, the electronic devices can work approximately 4-6 hours if they are charged at 100%. The minimum of working hours is 2 hours 30 minutes.

Conclusion

All in all, this set of tests showed that the manufacturing company has really increased the working hours of new gadgets in comparison with Galaxy Note 5 in each modification except the Wi-Fi connection. A non-trivial role the innovative function Doze Mode in Android Marshmallow system played, thanks to Google developers. Actually, the Exynos version holds the charge better than Snapdragon in 10-20%.

Stars: 1Stars: 2Stars: 3Stars: 4Stars: 5 (1 votes, average: 5.00 of 5)
Loading…

How to recover Li-Ion battery: a few available tips



Modern batteries are stay to be one of the biggest problems as for the manufacturers as well as for consumers. And it’s not just potential flaming risk, but the slow draining of the source power. So it shouldn’t come as a surprise that charging battery on the regular basis makes them work not more than a year or two with active use, after then their capacity is drastically decreasing and using your precious device becomes problematic. It’s impossible to completely restore a fully drained battery, but to extend the usage, while looking for new one is quite possible. So that’s what we’ll talk about today.

The following recommendations are for advanced users. So if you can’t make heads or tails of soldering tool it would be better to contact customer service or you could just go straight to local electronic store for a new battery.

Phone with a modern Li-Ion battery

Method №1

It can be useful in cases when battery generates gas due to continuous usage, as a result it gets bulged and can’t hold its charge.

Required tools and materials are: soldering iron, epoxy, fine needle, a heavy flat object for alignment.

  1. Carefully detach battery case from upper block with sensor
  2. Separate electric sensor
  3. There should be a cap. Inside that cap the control electronics is located.
    Accurately pierce it with the needle. Keep in mind that damaged electric inwards will make following battery restoration impossible.
  4. Considering the battery size you should find a heavy flat object witch should be slightly bigger than the battery.
  5. Here’s the crucial moment. Put the Battery on a table and create some pressure on it with press. Note that making to much effort can cause battery to be damaged, as well as making less effort could not give required result. It’s strongly recommended not to use any kind of vice or other similar purpose tools.
  6. When everything is done put a drop of epoxy on the hole and solder the sensor
Tools and materials for phone battery diagnosis

Method №2

This method will not completely revive the battery with much reduced resources, but will certainly make it work for some time. You shouldn’t count much on it, but it would provide some power for your smartphone, while you’re looking for new battery.

Required tools and materials: any power supply (5-12V, AC not less than 0.1 A), voltmeter or tester to monitor the voltage, resistor (capacity should be at least 500 mWt, resistance of 330 Ohm to 1000 Ohm)

  1. If you don’t have any power supply, it’s ok to use one from your network equipment (e.g. switches, routers, modems). You should be sure that AC options are meet the requirements.
  2. Release the contacts from power supply and connect them with drained battery: power supply “minus” with battery “minus”. “Plus” line ads with resistor. Check the correct polarity with multimeter.
  3. When everything is prepared, connect the power supply to the network. Procedure should take approximately 2-3 minutes. If possible, control process with tester: maximum voltage must not exceed 3.3V

A few important notes

  • Do not leave problematic battery unattended. The cases of spontaneous ignition is not a theory, but a harsh reality.
  • Periodically check the temperature of the battery with the use of bypass thermocouple, electronic thermometer or just by hand. If the surface feels to be hot, not just warm, immediately stop repairing.
  • Do not use excessive charging currents. The maximum you can afford is 50 mAh. This parameter is calculated as follows: voltage of power supply divided by the capacitance of the resistor. For example, if the first parameter is equal to 12V, and the second is 500 Ohms, the charge current will be equal to 24 mAh.
  • Instead of a resistor, you can use a standard 80mm computer fan.
  • In order to avoid spontaneous ignition it is recommended to control the initial charging of the restored battery

Method №3

This Method is controversial and questionable, although according to dedicated forums it helps some users, so the responsibility for any negative consequences lies with you.

Required tools and materials: a working fridge.

  1. Take the broken battery out of your smartphone and put it in a plastic bag, then the bag must be put in the freezer for 20-30 minutes
  2. Then take it out and put it back in your phone, and start charging for 1 minute
  3. remove it from the device again, let it warm up to room temperature, then charge as usual..

Method №4

Innocuous, but less than effective recovery method. But if you think that your smartphone’s battery is ultimately out of order, why not try it?

Tools and materials required: smartphone with standard battery charger.

  1. Discharge the battery completely (up to the stage when the phone can not be switched on). Any resource-intensive game or AnTuTu utility may prove helpful for this.
  2. Fully charge the battery up to the 100% level.
  3. Repeat points 1 and 2 several times.

Method №5

Almost all professional electricians will consider procedures described below a blasphemy, but many users of old batteries have proved this method to be helpful.

NOTICE: I strongly discourage you from using this method unless you have tried other, less risky ones.

Tools and materials required: razor blade, skinny screwdriver, ‘Moment’ glue.

  1. Retrieve the battery from your phone.
  2. Peel off the technical specification label.
  3. Remove as much of the top plastic cover, that protects control electronic components, as possible.
  4. Find main contact elements.
  5. Short-circuit them just for an instant with the help of any metallic object.
  6. Glue the top cover back and let the glue dry off.I want to draw your attention to the fact that none of the methods above guarantee a 100% result, and the whole responsibility falls utterly on your shoulders. But if the battery shuts off completely and buying a new one is not the prospect of your immediate future, you should try them out. In case your rarely find yourself in the process of soldering something and have no head for science, it’s safer to ask a friend who is well-versed in such things.

Video Tutorial

Stars: 1Stars: 2Stars: 3Stars: 4Stars: 5 (No votes yet)
Loading…

How to restore the screwdriver battery and its capacity? Is it possible to restore the screwdriver battery?

Hand electric screwdriver isolated on white.

The screwdriver is an important household tool, but the time goes and its energy source – the battery stops working. Models are constantly changing and finding the right battery can sometimes fail. However, you can completely restore it or extend it’s life by 2-3 years. This article tells how to repair a screwdriver battery.

Battery disassembly

Solving the question of whether it is possible to restore a screwdriver battery, we must first of all understand how to extract elements from it. The battery is housed in a plastic housing of two halves. First, unscrew the connecting screws. If the connection is made by glue, then you have to tinker with a screwdriver or a chisel. Disassemble carefully, so that you would be able to seal the case again. Inside there are elements connected in series. In some designs, a parallel-serial connection is used.

Substitution of elements

Solving the question of how to restore a screwdriver battery, it is necessary, first of all, to identify faulty banks that spoil its work. If the battery is dead, it needs to be charged, and then you should check up the voltage of all elements. It should not differ from the nominal by more than 10%. Repairment here means to restore the battery capacity of the screwdriver generally. It is affected by the health of each element. It must have a specified capacity, which is understood as the ability to feed the load connected to it.

Sometimes it is better to replace the failed components, which get discharge quickly. They can be detected by corrosion damage or the presence of characteristic traces of electrolyte on the surface. One or two elements can be a serious obstacle in the work of the entire line. If the battery is used for more than 3 years, then most of the elements can be faulty. In this case, it is better to replace them all. It is important that they are suitable for voltage and size.

The cost of accumulators assembled separately is lower than the new ones. The serviceability of each bank is checked by the value of the internal resistance, which should be about 0.06 Ohm. To do this, a load is connected to it (a resistor of 5-10 ohms) and at the same time the amperage and voltage are changed. It is convenient to use low voltage incandescent lamps. Measurements are made with two different resistances, 30% and 70% of the permissible load, respectively. From the 1st voltage, the 2nd is subtracted, and from the 2nd amperage — the 1st. Then the results of the subtraction are divided and, in accordance with Ohm’s law, we find the internal resistance of the battery.

The battery is often sold with an extra one. You can assemble one from two and still have the banks left. It is desirable to use them somewhere as power sources, for example, for a flashlight with a car lamp. After the diagnostics, the checked items are connected in a line. The matched kit must be welded in the same order. The bank body has a negative polarity, and the middle bar — positive. Then, without assembling the battery, you need to connect a charger to it. It is necessary to control the temperature of the elements. If they are in service, then there should not be too much overheating.

At the end of the charging time, and also after a day, the voltage of each element should be measured. If any battery is discharged by more than 10%, it needs to be replaced with a new one. After the battery passes the test, you can finish assembling its case. The fastening screws are screwed on the places accordingly to the sizes, and acetate-acrylate (“Super-glue”) is applied as a glue. With a competent selection of items, the battery will serve as a new one. After charging, it should be subjected to intensive training, giving a maximum load to the screwdriver, until it is discharged. Such cycles should be repeated 2 more times, and then – 1 time per quarter.

Restoring banks

Don’t throw away the batteries that failed test. The main reason for their failure is the evaporation of water through a rubber band located between the body and the middle tire. When it is full “zero”, the battery is momentarily charged with a 12V voltage impulse through a resistance of 40-50 ohms. While doing this, you should check that the case does not overheat. If there is still no voltage on it after that, then you can throw it away. To restore the electrolyte, some craftsmen drill mini holes for the syringe needle in the side groove of all battery cells. Then the banks are filled with distilled water. After that the batteries should not be touched for a day. The battery is then “trained”, charged and checked the voltage on each cell. The holes are sealed with silicone.

How to repair a screwdriver battery

All batteries look similar from the inside. They consist of successively welded banks. As a result you get the total battery voltage on the output contacts. The following types of elements are used: Ni-Cd (nickel-cadmium, U = 1.2 V). Ni-MH (nickel-metal-hydride, U = 1.2 V). Li-Ion (lithium-ion, U = 3.6V).

“Interskol” screwdriver battery

Screwdriver “Interskol” is one of the most popular, due to its versatility. In addition to the main function, it can also be used as a drill. You can use any of the common batteries in it. Nickel-cadmium and metal-hydride are used more often, as cheaper and more powerful ones. To ensure that they work reliably, they should be fully discharged and recharged to fully utilize the charge. Otherwise, the life of the equipment is significantly reduced. Reversible loss of capacity of an incompletely discharged and charged element is called a memory effect.

Lithium-ion batteries do not have this disadvantage, but their price is much higher. During the work, when every minute counts, a small charge is often required to maintain the required power of the screwdriver. In this case, these batteries are

indispensable, because their capacity can be quickly restored. The customer selects the battery of the screwdriver “Interskol” on his own, depending on the preferences, capabilities and required work. In most cases, nickel-cadmium batteries are used. How to restore the battery of the screwdriver “Interskol”, if it has not been used for a long time? When operating it is necessary to try to not let the voltage drop down to zero. You can discharge a 1.2V bank up to 0.9V. If the battery is completely discharged during long storage, the charger may not “see” it. It is necessary to “push” the battery with another, more powerful power source, so that a small voltage appears on it. After that, you can connect it to a standard charger.

Restoring “Makita” screwdriver battery

Before you restore the battery of the Makita screwdriver, first you need to disassemble its case. It consists of 2 halves, glued together. If you carefully tap the battery case with a rubber mallet, the adhesive will fall behind. There may be problems with disassembly of some parts. You may need to use additional hand tool. Next, disconnect the halves of the case, holding the screwdriver terminals. According to the performance characteristics, the drill-screwdriver “Makita” is close to the network tool. The autonomous power supply is provided by 2 replaceable Li-Ion batteries. Computer charging technology allows to recover them in just 22 minutes. At the same time, the battery life is significantly increased. Defective banks should be replaced with similar new models. If they are difficult to find on sale, you’ll have to make one of two accumulators. Factory welding can be contact, and during repair it is necessary to create a connection by soldering.

How to repair a Bosch screwdriver battery

Bosch screwdrivers are great for non-professional use. They have accumulators with Ni-Cd elements. They withstand large voltage loads, but quickly self-discharge (during 3-4 weeks). At least once a month they must be restored in order not to fail. In addition, in the process of operation there is an unbalance of the elements and the capacity is lost as time goes by. One of the ways to restore is to disassemble the case and “train” each element separately. If this doesn’t help the way desired, some of them will have to be replaced. Then the battery will last a long time.

Repairing the Hitachi Screwdriver Battery

How to repair a Hitachi screwdriver battery? Both Ni-Cd batteries must be charged, after that they should be disassembled and you should measure the voltage on each bank with a load of 1.5 ohms. Elements showing a lower voltage can be thrown away, and you can make 1 good battery from other good ones. Only 1 or 2 banks can damage the battery. How to restore the battery of the Hitachi screwdriver, as well as all other models, depends, first of all, on the type of elements installed in them.

Repairing the Aeg screwdriver battery

A screwdriver come with 2 batteries in the box. If one of them does not charge, this does not mean it’s broken. It may be discharged too much. In this case, you can try to “train” the battery by applying a pulsed voltage to it, and then put it on charge. The easiest way is to connect to a charged battery for a few seconds. If the recovery of the Aeg screwdriver battery the way described above failed, them its case should be disassembled and each bank checked.

Battery maintenance tips

If the battery has not been used, it should be discharged once a month by the permissible load and recharged again.

It is advisable to buy a screwdriver with two batteries in the kit.

Screwdrivers must be stored and used in conditions that prevent moisture from getting inside.

Conclusion

How to restore a screwdriver battery? There are several ways. Before disassembling it, we must try to find the cause of the malfunction, which can also be a mechanism or a charger problem. Observing the rules of battery operation, stated in the instruction, it is possible to significantly extend its life time.

Stars: 1Stars: 2Stars: 3Stars: 4Stars: 5 (1 votes, average: 5.00 of 5)
Loading…

Nexus 5 Battery Replacement Exposed

Lies You’ve Been Told About Nexus 5 Battery Replacement

The S pen on the phone also offers you easy and quick access to several applications, utilizing the Air Command menu. The tablet includes the updated Nokia Camera app, together with a selection of software to additional edit and improve the images and videos on the gadget. Most modern Smartphones use this architecture. The Lumia 520 is still an extremely capable phone and still is among the least expensive smartphones ever. Should itn’t, it is among the installed apps on the phone that is the reason for the issue. Google sent along their very first party Qi wireless charger too and I had an opportunity to take a look.

nexus 5 battery replacement

The battery, nevertheless, is non removable. For instance, you might have a battery with higher capacity, but the phone incorporates many power-consuming features (for example, a big screen) that creates a mobile with 4,000 mAh battery and 6 in. screen be up for equal time as a 2,500 mAh battery with 4.7 in. screen phone. For example, if you already have a laptop and an iPad mini, it is not likely you will want to put money into an Ultrabook.

On board the phone is a few of the strongest hardware readily available on the market today. Anyway, both phones are intended for completely different audiences. The phone has all of the significant connectivity alternatives. It is available in variants. Both phones almost look like twins which were separated at birth, since they have the exact same hardware on them. Mobile phones include a wide selection of battery capacities.

All 3 phones are offered in dual-SIM variants. The phone is predicted to acquire its share of KitKat soon, and ought to bring in lots of performance enhancements. It also comes with a CPU. It features a solid construction and a great display. Individuals now want to understand more on the topic of new mobile phones, latest technologies, upgraded features, mobile phone accessories and other mobile phone related applications.

The Death of Nexus 5 Battery Replacement

In spite of the device you pick, it has to effectively perform to its entire capacity. Screen dimensions and type are extremely important elements. You might also wish to have smaller screen sizes with 4.7 in. display like Google Nexus 5. The Moto X is a really good looker, with only the ideal dimensions and curves. You’re able to read more on the topic of the Moto X here in order To sum this up, we’d say that the Moto G lives up to each word that it’s claimed to be, `an exceptional phone for an exceptional price’. The HTC 1 Max completes the 1 family. In addition, it will come with 2 GB of RAM to make sure smooth multitasking.

On the base of the Nexus 5X there’s an USB-C port and a 3.5millimeter headphone jack. In cases like this, it is quite important because the present output isn’t labelled on the USB output ports. You may be wondering how important the present output is.

The device also includes a selection of sensors which could detect gestures. Although it is pretty solid, and looks elegant, it is quite a fingerprint magnet. Both these devices are very capable and are, undoubtedly, the most effective phones offered on the market today. Don’t, however, expect to get blown away by its performance, even though it is certainly not a slow device. It wasn’t charging any device and thus it doesn’t actually display the present output. After the Android device was seized and is secure, it’s time to inspect the telephone. The operating process might be one of the main judging criteria while selecting a telephone.

If you’re shipping an item over $75, you need to consider employing a trackable delivery service or purchasing delivery insurance. Camera quality is a rather significant factor for those who wish to take photos all the moment. Till only about a couple of years past, the automated pick for anyone looking to purchase a cell phone was Nokia. You might also start looking for different alternatives for the app. The incorporated wireless charging option on the gadget is really a nice touch. The optimal/optimally part is that there’s just one button at the side. It has a rather good logo on the base of the power bank.

The display employs a PenTile matrix as opposed to the regular RGB subpixel arrangement. If you would like large screens, you should choose a phone with 5.5 in. screen or more. On the opposite hand, its camera has arrived in for some severe criticism, and has come to be the middle of ridicule. The superb camera is ably supported by some authentic cool apps and characteristics that get the most out of the on-board optics. The camera UI is pretty intuitive and easy to use. It isn’t exactly the type of light you may use to read in the dark. The built-in light is yet another bonus.

Stars: 1Stars: 2Stars: 3Stars: 4Stars: 5 (No votes yet)
Loading…

How to Turn a Car On With the Discharged Battery

There are 4 easy and effective way to revive a car. Detailed instructions are included.

Sometimes low temperatures cause unpleasant surprises even to those who regularly change the battery in a car. If it’s -25°C or even colder, a fully serviceable battery loses up to half of its capacity per night: the accumulator acid condenses, the flux of the chemical reactions slows down and the battery cannot give the stored energy up.

Driving in the urban cycle with the heater, mirrors and seats heaters that are turned on do not contribute to the proper battery charging. Moreover, you may simply forget to switch off the parking lights or other appliances after parking.

If the battery is discharged, you will hear some prolonged sounds as wells as clicking of the starter when you try to start the engine. You will also notice dim glow of the indicators on a panel, which becomes even weaker when the key is turned.

If the accumulator does not show any sign of functioning, do not begin to panic immediately. There are no catch-22 situations. There are at least four ways to revive a car even if the battery is flat.

How to Start the Car by Jump-Starting

It is a universal and the most correct way of resuscitation. This method is the most popular among drivers. It is suitable for injection, gasoline and diesel cars with any type of transmission.

What is necessary?
● A jump car with a fully charged accumulator.
● Start-up wires with the “crocodile clips”.

Unless such an unpleasant situation has occurred in the deep forest, there should be no problem in finding a jump car. But it is likely that there will be some difficulties with a set of start-up wires. If there is no such equipment in the trunk, you can only hope that the other driver would be more prudent

What do you have to do?

It is important to observe the correct sequence of actions in order to start a car with a discharged accumulator successfully and not to damage a jump car:

1. Put the cars next to each other, bumper to bumper, or bumper to the wing. The choice will depend on the location of the battery.
2. Turn off the engine of a jump car and switch the ignition off in order not to burn the electronics.
3. Link positive sides of the both batteries with a red start-up wire. The charged battery should be the first.
4. Take one end of the black wire and connect it to the engine block or other metal part of the engine of your car. You should remember that these parts of your car should be located far away the fuel system. Use the other end of a black wire to link to the negative terminal of the battery of a jump car.
5. Attempt to start your car from the 2d or 3d time.
6. After the engine has been started, let it work a few minutes and disconnect wires in return sequence.

Do not try to jump-start from a subcompact car with an engine capacity of more than two liters, especially if it is diesel. A jump car`s engine should have greater or equal capacity as compared to the capacity of the battery that should be recharged. Moreover both devices should have the same power. 24 V battery cannot be used to start the 12 V battery and vice versa.

How to Start the Car by Kick Starting or Using a Tug

It is a classic, even obsolete method. It means that the engine is started by racing of the engine and gear actuation. In such a way you can start an injection engine, only if the battery is not fully discharged and its charge will be enough for gas pump to pump the fuel from the tank into the system. This method is effective only for cars with manual transmission.

What is necessary?
A tow rope.
● Other working cars or assistants.

Even if you are in a not crowded place and cannot find another car, then at least you will be able to find a couple of partial volunteers who will be ready to push your car. Actually, there always should be a rope in the trunk.

What should you do?
The method is very simple and does not require any special skills other than conditioned signals and actions coordinated with all active participants.
1. Connect both cars with a tow rope.
2. Start up the ignition of your car, depress the clutch pedal and go to the third gear without releasing the clutch pedal.
3. Give the command to the driver of the hauling car to start moving.
4. After accelerating a car to 10-20 km / h, release the clutch slowly.
5. When the engine starts, depress the clutch again and give a signal to another driver.

Do not hurry to go to neutral and let the engine run with the depressed clutch pedal. Otherwise it can immediately stall due to the cold oil in the transmission. Keep it in mind, if a car is pushed by the strong volunteers.

How to Start a Car with a Rope

It is relatively difficult way to start a car. However, it will be helpful if there is no one who can assist you. This method is suitable only for cars with a manual transmission.

What is necessary?
Tire jack.
A tow rope or a rope.

In each car there is a tire jack. A tow rope is also important part of the equipment of your car. If there is no tow rope at hand, you can use any rope the length of which is 2-3 meters.

What should you do?
1. Apply the parking brake and put stones or other supports under the wheels.
2. Use a tire jack to lift the car. After such a manipulation one of the traction wheels should be in the air.
3. Start up the ignition and go to the third gear.
4. Wrap a few turns of the rope tightly on the wheel and pull the car abruptly (you can run away to the side).
5. If you fail to start the engine from the first time, repeat all the actions.
6. When the engine starts, go to the neutral, put the car down by removing the tire jack.

By no means do not attach the cable to the disc or spool it on hand. Otherwise, after running the engine, there is a risk of getting seriously injured when a cable takes up the rotating wheel.

How to Start the Car with the Help of a Battery Booster

Battery boosters are the most technologically advanced way of starting a car with a dead battery. Thanks to the lithium iron phosphate battery these tiny gadgets are capable of giving much battery current even at low capacity. This method is suitable for injection, gasoline and diesel cars with any type of transmission.

What do you need?
Booster

The plus of the battery boosters is that they are completely autonomous. In addition to the booster itself, you will need nothing more to run a car. The downside of the gadget is that is relatively expensive.

What should you do?
Each booster comes with the detailed instructions, but in general the principle of their functioning is the same.

1. Cut off the ignition in a car.
2. Link the “crocodiles” of the booster to the battery terminals. Give attention to the polarity.
3. Start the car.

Even if it is cold and with the dead battery, the cars with engine capacity of up to two liters are started by the boosters without any problems. There can be difficulties only with the engines, especially with the diesel ones, with the volume of more than two liters.

How to avoid discharging
1. To avoid unpleasant situations it is advisable to monitor the state of the battery and replace it in time, lest it get fully discharged.
2. When starting the engine, always depress the clutch pedal. In such a way a starter won`t need to rotate the transmission gear in the solidified oil. It will facilitate the process as well.
3. If you have an important trip, we advise you to remove the battery from the car and take it home for the night. In such a way you will get more chances that the engine will run in the morning.
4. And certainly do not forget to turn the standing lamps and other devices off after parking.

Ending

It is always better to have an autonomous battery booster, then jacking a car in an unfamiliar area during a cold night. Be ready and take care of your nearest and dearest in advance.

In the comments tell if you happened to start a car with a dead battery. If you have had such an experience, describe the method you have used to start a car.

Stars: 1Stars: 2Stars: 3Stars: 4Stars: 5 (2 votes, average: 5.00 of 5)
Loading…
Comodo SSL
